Kepler products are engineered for the Canadian climate, prioritizing your comfort and well-being. A Central-Kepler heat pump system ensures a tranquil home environment, providing year-round warmth and cooling with whisper-quiet, energy-efficient performance.
Whisper-Silent Operation
Experience the ultra-quiet performance of our heat pump, thoughtfully designed to enhance home comfort with minimal noise disturbance. The indoor unit operates at a whisper-soft level, creating a serene and relaxing indoor environment. Meanwhile, the advanced engineering of the outdoor unit delivers remarkably quiet operation, with noise levels as low as 58 dB(A)—allowing you to fully enjoy your outdoor space in tranquility.
Effortless Integration Into Any Space
KEPLER’s modern side-discharge condenser is engineered for maximum space efficiency, boasting a design that is up to 40% more compact than traditional heat pumps. Its streamlined footprint not only enables greater installation flexibility but also enhances the overall aesthetic appeal of your space.
Qualifies for Rebate Programs
Creating a healthier, more sustainable home is easier than ever with a range of grants and financial incentives offered by various government programs. These initiatives are designed to improve home comfort while helping you reduce energy expenses.
Suitable for Any Climate
Our heat pump is meticulously designed for versatility and durability, delivering reliable performance in all climate conditions. Whether facing the gentle warmth of temperate regions or the harsh cold of extreme winters, this system ensures consistent indoor comfort year-round. Engineered to withstand diverse weather challenges, it maintains optimal functionality regardless of outdoor temperatures. With our heat pump, your home remains a haven of comfort, no matter the climate.
Cutting-Edge Inverter Technology
KEPLER heat pumps lead the way in energy efficiency with their state-of-the-art Inverter drive technology. By minimizing unnecessary start-stop cycles, they drastically cut energy consumption while ensuring seamless operation. Their ability to adjust output in precise 1% increments up to full capacity allows for precise temperature control with maximum efficiency. This advanced modulation not only enhances comfort but also optimizes energy use, delivering superior performance with minimal waste.
AHRI# | 213062294 | ||
Capacity | 24K | ||
Indoor | AZPN/B24WAC | ||
Outdoor | AZPNS/24ROD | ||
Power supply (Outdoor) | V- Ph-Hz | 208/230V,1Ph,60Hz | |
Cooling (Standard conditions) | Capacity (range) | Btu/hr | 24000(9800~28200) |
Input | W | 2400(380~2990) | |
Current | A | 9.0(1.0~12.0) | |
EER2 | Btu/hr/W | 10.0 | |
SEER2 | Btu/hr/W | 15.7 | |
Heating (Standard conditions) | Capacity (range) | Btu/hr | 25600(9700~31000) |
Input | W | 2246(510~3000) | |
Current | A | 8.5(2.0~12.0) | |
COP | W/W | 3.34 | |
HSPF4 | Btu/hr/W | 9.8 | |
HSPF5 | Btu/hr/W | 8.0 | |
Heating(H42) 5F(-15℃) | Rated capacity | Btu/hr | 18500 |
COP | W/W | 2.20 | |
Capability ratio | % | 72.27 | |
Throttle type | / | TXV for cooling | |
Indoor unit | Dimension (W*D*H) | mm | 445x533x457 |
Dimension (W*D*H) | inch | 17.52x20.98x17.99 | |
Packing (W*D*H) | mm | 505x650x490 | |
Packing (W*D*H) | inch | 19.88x25.59x19.29 | |
Net/Gross weight | kg | 19.4/23.6 | |
Net/Gross weight | lb | 42.77/52.03 | |
MINIMUM CIRCUIT AMPACITY (Outdoor) | A | 19 | |
MAX. FUSE (Outdoor) | A | 30 | |
Outdoor noise level | dB(A) | 61.5 | |
Throttle type | / | EEV for heating | |
Outdoor unit | Dimension (W*D*H) | mm | 890x342x673 |
Dimension (W*D*H) | inch | 35.04x13.46x26.50 | |
Packing (W*D*H) | mm | 995x398x740 | |
Packing (W*D*H) | inch | 39.17x15.67x29.13 | |
Net/Gross weight | kg | 46.4/49.5 | |
Net/Gross weight | lb | 102.29/109.13 | |
Refrigerant type | R410A | ||
Energy Star Certified | ccASHP |
